JB Pumps India Pvt. Ltd. is leading Manufacturer and Supplier of Submersible Slurry Pump. We manufacture Submersible Pumps for various industrial requirements.
Submersible slurry pumps are pumps designed to handle abrasive and high-density slurries in submerged conditions. These pumps are designed to operate underwater, with the motor and pump unit submerged in the slurry they are pumping. The submersion of the pump unit ensures that the slurry is kept contained and prevents it from leaking into the surrounding environment.
The selection of submersible pumps can be done based on several specifications. Choosing the first and leading submersible pumps mainly depends on type, application, and after that, the utmost flow of discharge must be decided. Submersible Sludge & Slurry Pumps by JB Pumps has great efficiency in handling the slurry. It can handle both solid and liquid material.
JBSL Series
JBSL series is designed to handle major heavy duty slurry applications across a very wide range. The excellent solid handling capability of our channel-impeller pumps guarantees maximum operating time and substantial reductions in maintenance costs caused by pump jamming or clogging and performs very efficient operation.
- Technical Specification of Submersible Slurry Pumps
- Submersible Slurry Pumps Material of Construction
| Motor | Four Pole Continuous Duty Squirrel Cage Submersible Type Induction Motor |
| Insulation Class | F |
| Protection | IP – 68 / Thermal Over Load / Moisture |
| Cable | PVC Insulated Double Sheathed Copper Conductor Flexible |
| Range | 2 HP to 100 HP |
| RPM | 1450 |
| Size | 2 inch to 8 inch |
| Connection | DoL or Star Delta |
| Motor Body | C.I./Alu.Alloy/SS |
| Pump Casing | C.I/Alu/S.S 304/S.S 316 |
| Impeller | CI , Aluminium, S.S 304 , S.S 316 |
| Shaft | S.S 410 / S.S 431 |
| Mech. Seal | Double Type: TC vs TC(Pump Side)/SIC vs SIC |
| Bearing | Deep Groove Ball Bearing (SKP) (Top) Double Row Angular Contact (Bottom) |
LOOKING FOR THE BEST SOLUTIONS IN PUMPS MANUFACTURING?
What Is Submersible Slurry Pump?
Submersible slurry pumps are designed to move slurry, sand, and other materials in the dredging, quarrying, and mining industries. Our non-clogging slurry pumps are built to handle the most challenging solids with the highest efficiency.
At JB Pumps India Pvt. Ltd., we manufacture high-quality submersible slurry pumps using advanced technology. Our pumps hold high pumping capacity and the ability to transfer abrasive media, like sand, with high solid content.
How Does A Submersible Slurry Pump Work?
Slurry pumps use the kinetic energy of the impeller to increase the flow and pressure of the fluid. Hereafter, the liquid enters the impeller inlet and moves through each stage. The liquid moves at high pressure and is forced out by centrifugal action from the volute discharge outlet.
Features Of Submersible Slurry Pump
- Excellent Solid Handling Capability
- High-Quality Sealing To Prevent Leakage
- Durable Bearings To Withstand Shocks And Overloads
- Portable & Lightweight Construction
- Non-Clogging Design
- Superior Wear & Corrosion Resistance
- Noiseless Operation
Advantages Of Submersible Slurry Pumps
- Can easily handle highly corrosive slurries
- Occupy less space as it can directly operate in the slurry
- The portable & lightweight design makes it more compact and quick to install
- Produces less noise and does the silent operation
- Built with robust material hence highly durable
- Wear and tear resistant from abrasive materials
- Consume low energy making it energy efficient and reliable
- Low maintenance costs and a longer service life
- The self-priming mechanism reduces the risk of pump damage caused by dry running
Submersible Slurry Pump Gallery
How To Select A Submersible Slurry Pump?
When selecting a submersible slurry pump, several factors should be considered:
Fluid Nature:
Identifying fluid characteristics is vital when selecting a submersible slurry pump. The pump should be able to transfer any liquid type, such as viscous, abrasive, and dense fluids, without damaging the impeller or pump parts.
Solid Size:
Before making a final purchase ensure that the slurry pump can handle the required size of the solids. Whether you require a pump to transfer sand, slurry, or sludge, the pump you choose should be capable of heavy solid materials with ease.
Material and Construction:
The slurry pump should be robustly constructed using durable and wear-resistant materials that can withstand abrasive fluids
Capacity and Head:
Determine the pump’s capacity and head and ensure the pump capacity matches the required flow rate while the pump’ head meets the required discharge pressure.
